Meeting 3P-EVI 380V/60Hz Air to water heat pump outdoor installation for low ambient temperature -25C

Meeting 3P-EVI 380V/60Hz Air to water heat pump outdoor installation for low ambient temperature -25C

  • Meeting 3P-EVI 380V/60Hz Air to water heat pump outdoor installation for low ambient temperature -25C
  • Meeting 3P-EVI 380V/60Hz Air to water heat pump outdoor installation for low ambient temperature -25C
Meeting 3P-EVI 380V/60Hz Air to water heat pump outdoor installation for low ambient temperature -25C
Product Details:
Place of Origin: Guangdong, China
Brand Name: Meeting
Certification: CE, RoHS, CCC,ISO,GMC,UKAS, CE,CCC,ISO,RoHS
Model Number: MD30D-31
Payment & Shipping Terms:
Minimum Order Quantity: 5
Packaging Details: Export standard plywooden case with water-proof film inside.
Delivery Time: 15
Payment Terms: L/C, T/T
Supply Ability: 2000piece/pieces per Month
Contact Now
Detailed Product Description
Warranty: 1 Year Power Source: Electric
Installation: Freestanding Housing Material: Coated Metal , Stainless Steel Can Choose
Application Field: Domestic,commercial,industrial Compressor: Copeland
Controller: LCD Finger Touch Throttle: Sanhua Electric Expansion Valve
General Using Places: Home,hotel,school,commercial Buildings
High Light:

evi air to water heat pump

,

heat pump unit

Meeting 3P-EVI 380V/60Hz Air to water heat pump outdoor installation for low ambient temperature -25C

Specification


Working air temp -25℃—45℃
Water flow 3000L/H
Pipe size DN25
Super quiet Noise ≤45Db
Evaporator Finned heat exchanger
Condenser Double pipe heat exchanger
Rated input power 2.98KW
Rated heating capacity 12KW
Hot water supply 196L/H
Rated voitage 380V/60HZ
Rated current 6A
Maximum outlet water temperature 60℃
Compressor Copeland

Remarks:The test conditions of above parameter :dry bulb temperature :20℃,wet bulb temperature :17℃, Inlet water temperature 15 degree , Outlet water temperature 80degree



Meeting 3P-EVI 380V/60Hz Air to water heat pump outdoor installation for low ambient temperature -25C 0



Meeting air source heat pump water heater features:


1. Complying with ISO standard. High Quality Ensured with the European standard.

2. Using reliable compressor( Copeland Scroll/Panasonic) with R417A/407C/R404A/R410A refrigerant.

3. Equipped with high efficiency tube in shell heat exchanger, finned heat exchanger or plate heat exchanger. All heat exchangers with insulation to prevent heat loss.

4. Evaporator using surface modification of wave hydrophilic aluminous foil .

5. Intelligent controller with LCD display control panel. Intellectual control over water pump, water supplement, water discharge and defrosting system.

6. Automatic defrosting function included (with reverse valve inside).

7. Low noise fan motor.

8. General and operational test carried out for every unit before package in the factory.





Packing & Delivery


Meeting 3P-EVI 380V/60Hz Air to water heat pump outdoor installation for low ambient temperature -25C 1

To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided, our package is ply-wooden case, needn't fumigation.







Company Profie


Our company have 19 years experience on manufacture heat pump and other home appliance, we build our own industry park, we have outstanding R&D team, we gain a lot of honor and certificate in the past years, and we never stop development in future.

Meeting 3P-EVI 380V/60Hz Air to water heat pump outdoor installation for low ambient temperature -25C 2







FAQ


Q1: Regarding our company

Our company establish in 2001, we are a manufacturer which have more than 18 years experences on produce heat pump.

We have own brand --Meeting.

We built our own industry park, our company is located in JinGu High-Tech-End Area, Huadu District Guangzhou, China, near Baiyun International Airport, welcome to contact with us and visit our company!



Q2: Regarding our products

Our products are manufactured strictly according to international standard. We got a lot of certifications and testing report; please kindly tell me if you need the certification.



Q3: Regarding the MOQ

The MOQ is 1 set, and we suggest using Alibaba Trade Assurance to protect both benefit.



Q4: Regarding the package

Our package is plywood with dusty-proof film, do not need fumigation.



Q5: Regarding delivery

Usually deliver by sea, for our regular equipment, deliver time is about 15 days. For OEM orders, will be further negotiate with us.
