School air to water Hydronic Heat Pump Support WIFI control Heating Cooling & Hot Water



Side blowing air to water source heat pump incluce cooling and heating features



Technology Specification





Quick Details

1. Rated heating capacity :  21KW

2. Rated Cooling capacity : 15KW

3. Hot water supply : 520L / h

4. Average heating input power : 5.68KW

5. Rated heating input current : 12A

6. Max outlet water temp : 60 ℃

7. COP : 4.2

8. Power : 380/50V / Hz

9. Noise :60 Db(a)

10. Dimension W*D*H :1120*490*1270mm

11. Packing size W*D*H :1200*520*1425mm

12. Unit weight : 210KG

13. Refrigerant : R417A/R407C/R404A

14. Working air temp range : (-20℃)—45℃

15. compressor : Copeland

16. Air source heat exchanger :    Finned heat exchange

17. Fan : axial flow fan

18. Hot water side heat exchange : Coil heat exchanger

19. Water flow : 6000L / H

20. Water pressure down : 48Kpa

21. Pipe size : 25DN

22. Max flat spuare meter M2 175 M ²





Product Advantage:

1 . The air source heat pump uses 1 part of electric energy and simultaneously obtains 2 or more free air energy (source) from the outdoor air. It can produce 3 or more pieces of heat energy, is highly efficient and environmentally friendly, and saves 75 % of the electricity bill per month compared to electric heating. By saving such a considerable amount of electricity, machine costs can be quickly recovered.

2 . Wide range of uses and no worries

3 .The air source heat pump can not only heat in winter but also cool in summer. It can meet the needs of winter and summer, and other heating equipment can only produce heating in winter. Air conditioning equipment is also required to be installed in summer cooling.

4 . Safe operation and environmental protection

5 . Condenstion heat exchanger  In combination with the United States and the United States outside the threaded pipe technology, successfully created a "spring" spiral tube new structure condenser. Better heat transfer, faster heat transfer, and higher efficiency, minimize fouling, extend heat pump life and reduce maintenance

6 . The air source heat pump adopts the form of heat pump heating, and the water and electricity are completely separated. No coal or natural gas is required. Therefore, the air source heat pump can be safely operated 24 hours a day throughout the year and will not cause environmental pollution (refrigerant leaks) e.

7. Low noise design for the outdoor unit. The compressor is on a floating plate to reduce vibration at the most extent. Noise insulation inside the cabinet. The fan is extremely quiet.

8 . Flexible, unlimited

9 . Compared to solar, gas, and water (ground) heat pumps, air energy (source) heat pumps are not affected by bad weather such as nights, cloudy days, rain, and snow, and are not limited by geology and gas supply.



ABOUT US

1). We were established in 2001.

2).We are a professional heat pump manufacturer,Located arround baiyun Air port

3). We are trading on Meeting Brand ,Meeting heat pump Well-know brand we operate in Europe market

4). Our company has been inspected and certificated by TUV and SGS.

5). We are the one of the first manufacturers whose heat pumps are with top COP gaining grants from Chinese government.

6). We pass ISO9001 quality management system and ISO14000 environment protection system

7). Our testing laboratory can test heat pump up to 60KW heating capacity and create testing air temperature condition during -25DegC~45DegC,according to EN14511 standard.

9). Our leading products: Air to water heat pump , DC inverter heat pump, High water temperature heat pumps

Monoblock house heating heat pumps ,Split heat pump ,Super low noise heat pump

Heat pump dryer ,Ground source heat pump , water to water heat pump , swimming pool heat pump





Packaging & Shipment 1>Meeting heat pump can sure delivery heat pump within 5~20 working days as we warehouse stock condition. 2>Heat pump with strong plywood pallet , strong plywood box for loading, make sure no problem happen during rude transporattion . 3>All spare parts of the heat pump water heater will together loading into package , one time finished shipment to buyer. 4>Take video of the heat pump for buyer before package to 100% sure buyer get product same as order, no any different. 5>Meeting heat pump offer 100% test online, 5% test in Lab by 24 hour for one lot order (if not new



Technical service

1. We calculate the capacity and recommend the best models.

2.We supply you the professional refrigeration technical support and electronic technical support for your installation, debugging and operation.

3. We supply the spare parts and technical support in and after the warranty time.

4. We supply the training course to your workers at our factory if you need.

5. We can offer site training to your workers in your place which is negotiable.



After-sales service

1 . Technical support for your installation, operation and maintenance.

2 . Standard warranty time: One years’warranty for heat pumps

You can also pay for extended warranty or we can renegotiate the longer warranty period.

3 . Spare parts and technical support at most economic prices after the warranty.



Certificsate we have got :

1> ISO 9001, ISO 14000

2> Our company has been inspected and certificate by EMC

3> CE And EN14511, EN 14825-ERP for heat pump exported to europe

4> Energy label for all heat pump models sold to oversea market

5> Testing laboratory calibrated by CNAS



Payment service

1. T/T

2. L/C (for container order only)



Technical service

1. We calculate the capacity and recommend the best models.

2.We supply you the professional refrigeration technical support and electronic technical support for your installation, debugging and operation.

3. We supply the spare parts and technical support in and after the warranty time.

4. We supply the training course to your workers at our factory if you need.

5. We can offer site training to your workers in your place which is negotiable.



FAQ

Q1. Can I have a sample order for Heat pump or Water tank?

A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.

Q2. What about the lead time?

A:Sample needs 3-10days, mass production time depend on the products'quantity.

Q3.Do you offer guarantee for the products?

A: Yes, 12 months since the heat pump depart from the port of loading (Refer to the Bill of Lading).



Certificsate we have got :

1> ISO 9001, ISO 14000

2> Our company has been inspected and certificate by EMC

3> CE And EN14511, EN 14825-ERP for heat pump exported to europe

4> Energy label for all heat pump models sold to oversea market

5> Testing laboratory calibrated by CNAS



Our leading products

Air to water heat pump , DC inverter heat pump, High water temperature heat pumps

Monoblock house heating heat pumps ,Split heat pump ,Super low noise heat pump



QC

1. Complying with ISO standard. Quality Ensured.

2. Complete Inspection for each unit before out of factory, covering water system and electricity detection and testing, ensuring 100% right product before shipment.

3. Strict quality control during production. We have liquid soap detection, halogen detection, electrical detection and water-soaking detection during production to avoid gas leakage and electrical problems .

4. Full inspection on bigger parts such as compressors, condensers, evaporators, expansion valves, flow switches, controllers etc.. Selection inspection for small parts such as sensors, pressure switches etc..

5. Well noise control by using mute cotton for casing plates and soft rubber feet for floating compressors, some of the models use compressor isolation shields.

6. Well insulated with insulated cotton for every pipe and parts, include compressor, dryer filter and each pipes.

7. We have passed TUV and SGS inspections. We have CE, RoHs, IEC, CCC, CB certificates for most of our products. Some of our products have en14511 test, en14825 test.
