Product Details:
Place of Origin: Guangzhou China
Brand Name: Meeting
Certification: CE ISO CCC UKAS,ROHS
Model Number: MDY150D
Payment & Shipping Terms:
Minimum Order Quantity: 5 PCS
Price: Negotiation
Packaging Details: Plywooden case
Delivery Time: 15 days
Payment Terms: T/T, L/C WESTERN UNION
Supply Ability: 800/MONTH
Contact Now
Detailed Product Description
Materail: Galvanized Steel Sheet Contactor: Fuji Brand
Copper Pipe Thick: 1 Mm Compressor: ZW Series ,With Crank Heating
Working Temperature: -20--45 Degree Insulation: Foam Pack Pipe And Stick On The Machine Innner
Defrosting: Automaticlly
Highlight:

electric heat pump for inground pool

,

inground pool heat pump

Meeting fish pool heat pump heater constant temperature swimming pool heat pumps hot comfortable water for swimming



Technology Specification





Constant temperature swimming pool heat pump

Hot comfortable water for swimming



MODEL Unit MDY10D
Rated heating capacity KW 3.5
Average heating input power KW 0.8
Rated heating input current A 6
Max outlet water temp 35
COP   3.8
Power V/Hz 220V/50
Noise Db(a) 48
Dimension W*D*H mm 1140×360×538
Packing size W*D*H mm 1180*380*680
Unit weight KG 70
Refrigerant   R417A/R410
Working air temp range (-20℃)—45℃
compressor Type   Panasonic
Air source heat exchanger Type   Finned heat exchange
Fan Type   axial flow fan
Hot water side heat exchange Type   Titanium heat exchanger
Water flow L/H 1200L/h
Water pressure down Kpa 30
Pipe size(water connection) DN 50
MODEL Unit MDY15D
Rated heating capacity KW 5.5
Average heating input power KW 1.25
Rated heating input current A 6
Max outlet water temp 35
COP   3.8
Power V/Hz 220V/50
Noise Db(a) 48
Dimension W*D*H mm 1140×360×539
Packing size W*D*H mm 1180*380*680
Unit weight KG 70
Refrigerant   R417A/R410
Working air temp range (-20℃)—45℃
compressor Type   Panasonic
Air source heat exchanger Type   Finned heat exchange
Fan Type   axial flow fan
Hot water side heat exchange Type   Titanium heat exchanger
Water flow L/H 1800L/h
Water pressure down Kpa 30
Pipe size(water connection) DN 50
MODEL Unit MDY20D
Rated heating capacity KW 9
Average heating input power KW 1.84
Rated heating input current A 7
Max outlet water temp 35
COP   3.8
Power V/Hz 220V/50
Noise Db(a) 50
Dimension W*D*H mm 1140×360×540
Packing size W*D*H mm 1180*380*680
Unit weight KG 75
Refrigerant   R417A/R410
Working air temp range (-20℃)—45℃
compressor Type   Panasonic
Air source heat exchanger Type   Finned heat exchange
Fan Type   axial flow fan
Hot water side heat exchange Type   Titanium heat exchanger
Water flow L/H 3500L/h
Water pressure down Kpa 30
Pipe size(water connection) DN 50
MODEL Unit MDY30D
Rated heating capacity KW 14
Average heating input power KW 3
Rated heating input current A 13/6
Max outlet water temp 35
COP   4
Power V/Hz 220V/380/50
Noise Db(a) 55
Dimension W*D*H mm 1120*490*790mm
Packing size W*D*H mm 1200*520*870mm
Unit weight KG 110
Refrigerant   R417A/R407C/R410A
Working air temp range   (-20℃)—45℃
compressor Type   Copeland
Air source heat exchanger Type   Finned heat exchange
Fan Type   axial flow fan
Hot water side heat exchange Type   Titanium heat exchanger
Water flow L/H 5500L/h
Water pressure down Kpa 40
Pipe size(water connection) DN 50
MODEL Unit MDY40D
Rated heating capacity KW 16
Average heating input power KW 4
Rated heating input current A 18/9
Max outlet water temp 35
COP   4.2
Power V/Hz 380V/50
Noise Db(a) 55
Dimension W*D*H mm 1120*490*1270
Packing size W*D*H mm 1200*520*1440
Unit weight KG 160
Refrigerant   R417A/R407C/R410A
Working air temp range   (-20℃)—45℃
compressor Type   Copeland
Air source heat exchanger Type   Finned heat exchange
Fan Type   axial flow fan
Hot water side heat exchange Type   Titanium heat exchanger
Water flow L/H 6500L/h
Water pressure down Kpa 45
Pipe size(water connection) DN 50
MODEL Unit MDY50D
Rated heating capacity KW 19
Average heating input power KW 4.4
Rated heating input current A 9
Max outlet water temp C 35
COP   4.2
Power V/Hz 380V/50
Noise Db(a) 55
Dimension W*D*H mm 1120*490*1270
Packing size W*D*H mm 1200*520*1350
Unit weight KG 160
Refrigerant   R417A/R407C/R410A
Working air temp range   (-20C)—45C
compressor Type   Copeland
Air source heat exchanger Type   Finned heat exchange
Fan Type   axial flow fan
Hot water side heat exchange Type   Titanium heat exchanger
Water flow L/H 7500L/h
Water pressure down Kpa 45
Pipe size(water connection) DN 50
MODEL Unit MDY60D
Rated heating capacity KW 26
Average heating input power KW 6
Rated heating input current A 12
Max outlet water temp 35
COP   4.2
Power V/Hz 380/50
Noise Db(a) 60
Dimension W*D*H mm 1120*490*1270
Packing size W*D*H mm 1200*520*1350
Unit weight KG 210
Refrigerant   R417A/R407C/R410A
Working air temp range   (-20℃)—45℃
compressor Type   Copeland
Air source heat exchanger Type   Finned heat exchange
Fan Type   axial flow fan
Hot water side heat exchange Type   Titanium heat exchanger
Water flow L/H 9000L/h
Water pressure down Kpa 48
Pipe size(water connection) DN 50
MODEL Unit MDY100D
Rated heating capacity KW 42
Average heating input power KW 9.2
Rated heating input current A 18
Max outlet water temp C 35
COP   4.2
Power V/Hz 380V/50
Noise Db(a) 60
Dimension W*D*H mm 1450×760×1060
Packing size W*D*H mm 1520*760*1190mm
Unit weight KG 289
Refrigerant   R417A/R407C/R410A
Working air temp range   (-20C)—45C
compressor Type   Copeland
Air source heat exchanger Type   Finned heat exchange
Fan Type   axial flow fan
Hot water side heat exchange Type   Titanium heat exchanger
Water flow L/H 15000L/h
Water pressure down Kpa 54
Pipe size(water connection) DN 63
MODEL Unit MDY150D
Rated heating capacity KW 50
Rated Cooling capacity KW 37
Average input power KW 11
Rated input current A 24
Max outlet water temp C 38
COP   4.5
Power V/Hz 380V/50
Noise Db(a) 60
Dimension W*D*H mm 1450×760×1060
Packing size W*D*H mm 1520*760*1190mm
Unit weight KG 320
Refrigerant   R417A/R407C/R410A
Working air temp range   (-20C)—45C
compressor Type   Copeland
Air source heat exchanger Type   Finned heat exchange
Fan Type   axial flow fan
Hot water side heat exchange Type   Titanium heat exchanger
Water flow L/H 18000L/h
Water pressure down Kpa 54
Pipe size(water connection) DN 63
MODEL Unit MDY200D
Rated heating capacity KW 84
Average heating input power KW 19
Rated heating input current A 35
Max outlet water temp 35
COP   4.5
Power V/Hz 380V/50
Noise Db(a) 65
Dimension W*D*H mm 1990*980*2080
Packing size W*D*H mm 2080×1150×2130
Unit weight KG 650
Refrigerant   R417A/R407C/R410A
Working air temp range   (-20℃)—45℃
compressor Type   Copeland
Air source heat exchanger Type   Finned heat exchange
Fan Type   axial flow fan
Hot water side heat exchange Type   Titanium heat exchanger
Water flow L/H 28000L/h
Water pressure down Kpa 60
Pipe size(water connection) DN 63
MODEL Unit MDY300D
Rated heating capacity KW 100
Average heating input power KW 25
Rated heating input current A 45
Max outlet water temp 35
COP   4.5
Power V/Hz 380V/50
Noise Db(a) 68
Dimension W*D*H mm 1990*980*2080
Packing size W*D*H mm 2080×1150×2130
Unit weight KG 650
Refrigerant   R417A/R407C/R410A
Working air temp range   (-20℃)—45℃
compressor Type   Copeland
Air source heat exchanger Type   Finned heat exchange
Fan Type   axial flow fan
Hot water side heat exchange Type   Titanium heat exchanger
Water flow L/H 45000L/h
Water pressure down Kpa 60
Pipe size(water connection) DN 63



Meeting lower running noise Air to water swimming pool heat pump water heater constant temperature and big water flowing





Packaging & Delivery

Packaging Details: export wooden packing

Delivery Time: 15-30 days





Swimming Pool Heat Pump heating:



* Long operating life

Using the advanced titanium in PVC or Nickel – copper in PVC shell & tube heat exchangers, which can resist corrosion from chlorine in the water.



* Economical and high efficiency

Using the more efficient heat pump technology, compared to other ordinary hot water equipment (for example, combustion oil boiler, comb-ussion gas boiler and electrical boiler),it reduces operation cost by 65%~80%,moreover,it produces little pollution for environment.



* Innovative design, easy installation and replacement.

Mono block (single unit conclusion) design, the unit is remarkable compact and easy to install.



* Advanced control

It is extremely easy to control the swimming pump unit because of the built-in computer with its intelligent control and LCD display.

*Use safely





Our Services



1. After installation, our company will be responsible for problems caused by quality of production or raw material except the damageable spare parts of heat pump caused by incorrect man-made operation during the guarantee period.



2. Intelligent Controlling service system will be avoid the long distance of the after sale problem. Wherever are you, our engineer can be controlled your equipment, when some questions occur on the equipment. Just tell us what number will be shown on the screen, then the engineer will be solve the problem.



3. We accept OEM, ODM and customization.



4. 24*7 after sales service. You will get satisfied service.



5. We have More than 17years production and sales experience; Professional sales team.



Swimming pool/bath/hotel heat pump water heater

Advantage feature

  • Excellent outlook design wins high appreciation
  •
  • Compact structure and good demountability
  •
  • Patented 100% titanium Heat exchanger in PVC & INOX Shell
  •
  • Intelligent Microcomputer controller
  •
  • High efficiency compressor with R417A / R407C / R410 refrigerant
  •
  • Air exchanger with hydrophilic coating
  •
  • Automatic defrosting function included
  •
  • Low noise.

Packing: plywood case

Lower Heat Dissipate Water To Water Heat Pump , Heat Pump Unit Stainless Steel Shell 0



Lower Heat Dissipate Water To Water Heat Pump , Heat Pump Unit Stainless Steel Shell 1

  • FAQ
  • What is your advantage, comparing with other water heaters?
  •
    • A: Avoiding electric water heater leakage, dry, high power consumption.
      B: Avoiding the drawbacks of gas water heater, such as producing harmful gases, Fits and starts etc.
      C: Energy efficient, safety and environmental protection, all-weather operation, easy to use.
  • What details do you need?

A: Pool: Length, width, depth.

B: Ambient temperature.

C: Water input and output temperature.



  • Will it be too trouble to use air water heater?

Easy to use, once set, always have hot/cool water



  • How long is the life of air water heater

Life span is 12-15 years



  • .How many years guarantee?

1 years
