|Place of Origin:||Guangzhou China|
|Certification:||CE ISO CCC UKAS,ROHS|
|Minimum Order Quantity:||5 PCS|
|Packaging Details:||Plywooden case|
|Delivery Time:||15 days|
|Payment Terms:||T/T, L/C WESTERN UNION|
|Materail:||Galvanized Steel Sheet||Contactor:||Fuji Brand|
|Copper Pipe Thick:||1 Mm||Compressor:||ZW Series ,With Crank Heating|
|Working Temperature:||-20--45 Degree||Insulation:||Foam Pack Pipe And Stick On The Machine Innner|
|Name:||High Efficiency Heat Pump||Temperature:||80 Degree|
high temperature air to water heat pump,
commercial hot water heat pump
Max. output hot water :80deg.C
Copeland ZW scroll compressor
Absolutely safe external control system
This series of air source heat pump is is specially designed for the highest water temperature can reach 80 deg.C.
It is adopted the most advanced high- temperature Enhanced Vapors Injection compressor technology.The heat pump performance has been improved greatly with Copeland high temperature scroll compressor from Emerson company and with Deron specially designed economizer and high efficiency heat transfer module.
1. Hot water output temperature up to 80°C.
2 .COP can be up to 3.5, when A20W15/80.
3. Eco-friendly refrigerant: R134A.
4. Auto- defrosting function included (with reverse cycle valve inside).
5. Anti-corrosion case: durable coating; no-screw design with stainless steel bolts and nuts, no rust.
6. General testing and operational test carried out for every before package in the factory.
7. Comprehensive protection, --- ensures trouble free operation in extremely cold ambient. Anti-freezing protection, Water flow protection, Over high pressure protection, Over low pressure protection etc.
8. Got EN14511 test report and CE certificate
High temperature heat pump
Impressed by the founder’s specialist knowledge and experience at refrigeration fields, helped by the closed cooperation with engineers from world famous companies such as Copeland, Emerson,Carel, Siemens, SWEP, Honeywell,etc.Meeting management team is keen to committed innovation to develop low carbon emissions heat pumps to fight for the world warming and power shortage.
We are heat pumps, chillers (water cooler), Pool Dehumidifer ,Heat pump dryer, fan coils manufacturer in China, with 18 years production and developing experience.
The main export market is Europe.
The products designed by European standard EN 14511, approved by ECM with its high efficiency.
Suitable for the coldest winter area
The most high efficiency heat pump
Indoor side installation
No noise level to disturb your neighbor
Adopt with world famous parts:
1) Copeland scroll compressor
2) Automaticly controller
3) Stainless steel plate type heat exchanger
4) electronic parts
5) Emerson expansion valve and dry filter
6) Honeywell 3 way revert valve is optional part
7) Adjustable low pressure switch
8) Wilo water pump (option)
9) 3KW electric heater (option)
