High Effieiency Water Cooled Heat Pump , Commercial Electric Air Source Heat Pump

Top blowing air to water heat pump 380V / 50HZ  High effieiency work heating water machine  use hotel factory porject engineering many aspects.

Technology Specification


Quick Details
1 Rated heating capacity 36KW

2 Rated Cooling capacity 24KW

3 Hot water supply L/h 800L / h

4 Average heating input power KW 9.2KW

5 Rated heating input current A 18A

6 Max outlet water temp  60℃

7 COP   4.2


Product Advantage:
1 . Compressor The world - famous Copeland Flexible Scroll Compressor has functions such as low wear resistance , long service life, over-current protection, phase loss protection , over-the - counter protection , strong liquid -impact resistance , and high and low voltage protection. Copeland compressor built - in pressure relief valve in the body can automatically relieve pressure when the high pressure is too high .

2 . Designed for central heating for houses in cold area including North Europe and East Europe.

3 . Electronic expansion valve The introduction of the latest Japanese technology in conjunction with the company's control system has led to the development of a unique electronic expansion valve control method and the use of digital technology control to control the working fluid to achieve the best flow velocity effect, thereby increasing the COP value .

4 . Can work with auxiliary heater.

5 . Condenstion heat exchanger  In combination with the United States and the United States outside the threaded pipe technology, successfully created a "spring" spiral tube new structure condenser. Better heat transfer, faster heat transfer, and higher efficiency, minimize fouling, extend heat pump life and reduce maintenance

6 . Electronic control system With powerful engineering supporting control functions , it can control circulating water pump, make-up water , return water, water supply , electric heating , PID automatic defrosting, etc., making the control easier. According to the needs of different projects, it can set various parameters by itself and realize various water supply schemes . The entire system can be automated without special care.

7. Low noise design for the outdoor unit. The compressor is on a floating plate to reduce vibration at the most extent. Noise insulation inside the cabinet. The fan is extremely quiet.

8 . The refrigerant connections are designed to allow hiding all pipes, wires into the ground to ensure good looking installation.

9 . Evaporation heat exchanger The use of hydrophilic membrane aluminum foil , even after long-term use The use of a hydrophilic layer also does not result in oxidative detachment. this The evaporator has a special advantage: Excellent skis performance The more you can reduce the wind resistance , so that the condensate drains out quickly outer. Internally-threaded copper tube and corrugated aluminum foil structure High evaporator efficiency .

ABOUT US
1). We were established in 2001.

2).We are a professional heat pump manufacturer,Located arround baiyun Air port

3). We are trading on Meeting Brand ,Meeting heat pump Well-know brand we operate in Europe market

4). Our company has been inspected and certificated by TUV and SGS.

5). We are the one of the first manufacturers whose heat pumps are with top COP gaining grants from Chinese government.

6). We pass ISO9001 quality management system and ISO14000 environment protection system

7). Our testing laboratory can test heat pump up to 60KW heating capacity and create testing air temperature condition during -25DegC~45DegC,according to EN14511 standard.

8). Our leading products: Air to water heat pump ,  inverter heat pump, High water temperature heat pumps
Monoblock house heating heat pumps ,Split heat pump ,Super low noise heat pump
Heat pump dryer ,Ground source heat pump , water to water heat pump , swimming pool heat pump




Technical service
1. We calculate the capacity and recommend the best models.

2.We supply you the professional refrigeration technical support and electronic technical support for your installation, debugging and operation.

3. We supply the spare parts and technical support in and after the warranty time.

4. We supply the training course to your workers at our factory if you need.

5. We can offer site training to your workers in your place which is negotiable.

After-sales service
1 . Technical support for your installation, operation and maintenance.

2 . Standard warranty time: One years’warranty for heat pumps
You can also pay for extended warranty or we can renegotiate the longer warranty period.

3 . Spare parts and technical support at most economic prices after the warranty.

Certificsate we have got :
1> ISO 9001, ISO 14000

2> Our company has been inspected and certificate by EMC

3> CE And EN14511, EN 14825-ERP for heat pump exported to europe

4> Energy label for all heat pump models sold to oversea market

5> Testing laboratory calibrated by CNAS

Payment service
1. T/T
2. L/C (for container order only)

We have test every machine in here before leave the factory to make sure every machine can working normal
