Home ProductsCommercial Heat Pump

Meeting 12KW CE Commercial Air Source Heat Pump high efficiency hot water for bathing

Meeting 12KW CE Commercial Air Source Heat Pump high efficiency hot water for bathing

    • Meeting 12KW CE Commercial Air Source Heat Pump high efficiency hot water for bathing
    • Meeting 12KW CE Commercial Air Source Heat Pump high efficiency hot water for bathing
    • Meeting 12KW CE Commercial Air Source Heat Pump high efficiency hot water for bathing
  • Meeting 12KW CE Commercial Air Source Heat Pump high efficiency hot water for bathing

    Product Details:

    Place of Origin: Guangzhou China
    Brand Name: Meeting
    Certification: CE ISO CCC UKAS,ROHS
    Model Number: MD30D-1

    Payment & Shipping Terms:

    Minimum Order Quantity: 5 PCS
    Price: Negotiation
    Packaging Details: Plywooden case
    Delivery Time: 15 days
    Payment Terms: T/T, WESTERN UNION
    Supply Ability: 800/MONTH
    Contact Now
    Detailed Product Description
    Materail: Galvanized Steel Sheet Contactor: Fuji Brand
    Copper Pipe Thick: 0.8-1 Mm Compressor: Copeland
    Working Temperature: -20--45 Degree Defrosting: Automaticlly
    Evaporator: Finned Heat Exchanger Condenser: Double Pipe Heat Exchanger
    High Light:

    domestic hot water heat pump

    ,

    water cooled heat pump

    Meeting 12KW CE Commercial Air Source Heat Pump High Efficiency Hot Water For Bathing





    Technology Specification



    Heating capacity: 12KW Rated water temperature: 55 ° C
    Water production: 280L/h Maximum water temperature: 60 ° C
    Rated power: 2.98KW Voltage / frequency: 380 / 50 V / Hz
    Rated current: 6A Interface size: 25DN
    Noise: ≤45Db(a) Water flow: 3600L/h



    Above parameters test conditions as follows: environment dry bulb temperature 20 ℃, wet bulb temperature 15 ℃.





    1. HIGH EFFICIENCY & ENERGY SAVING:

    Meeeting Air Source Heat Pump Water Heater COP >4 , Saving 70%~80% electricity cost.(7dC Ambient Temp,35dC Output Water Temp)



    2. HEAT PUMP COMPRESSOR:

    Meeting Air Source Heat Pump use Famous Brand scroll ZWKSE series compressor and environmentally friendly refrigerant R407C/R410A/R417, stable working at -25dC ambient temperature.



    3. HEAT PUMP EXCHANGER:

    Use high efficient tank heat exchanger for heating & domestic hot water. Stainless steel plate heat exchanger for heating & cooling.



    4. AUTOMATIC DEFROSTING:

    Automatic defrosting and power-off memory function.



    5. INTELLIGENT MICROCOMPUTER SYSTEM:

    With LCD panel, can mannually,automatically switch heat pump unit on/off, timer switch unit on/off, fault alarm, fault code display.



    6. MULTIFUCTIONAL SELF-PROTECTION:

    Phase sequence protection, high and low pressure protection, current protection, high and low temperature protection, antifreeze protection on low temp Heat Pump.



    7. ANTI FREEZE:

    Add chassis electric heater to avoid condensate water freezes in winter.





    Extraordinary Features for Meeting Air to Water Heat Pump:



    1> Hot water output temperature up to 60°C



    2> Copeland scroll type compressor with multi-functional protectors



    3> With auxiliary heating control, circulation pump control



    4> With timer function



    5> Adjustable defrosting, and all weather operates on varied extreme weather conditions



    6> Stable water flow switch



    7> With terminal for indoor thermostat, starting or standby the heat pump



    8> Air exchanger (fin-coil) with hydrophilic coating



    9> Low noise fan motor, 15 years lifespan



    10> Emerson expansion valve, Saginomiya 4-way valve



    11> Modular designing, addtional unit could be added onto to user's requirements



    12> Axial type fan motor with nylon fan blades, low power consumption, low running noise, long usage life



    13> Tube in tube heat exchanger produced by Meeting is low-fouling and easy for maintenance.



    14> Anti-corrosion case: coated steel or #304 stainless steel cabinet with elegant workmanship



    15> Power-saving, free-polluted, efficient & economic operation



    We have to test evey machine here before it leaves the factory, To make sure every machine work normally and the high temperature can achieve  60℃







    Adopt with world famous parts:



    1) Copeland scroll compressor



    2) Automaticly controller



    3) Stainless steel plate type heat exchanger



    4) electronic parts



    5) Emerson expansion valve and dry filter



    6) Honeywell 3 way revert valve is optional part



    7) Adjustable low pressure switch



    8) Wilo water pump (option)



    9) 3KW electric heater (option)





    Advantages



    1. Suitable for the coldest winter area



    2. The most high efficiency heat pump



    Meeting 12KW CE Commercial Air Source Heat Pump high efficiency hot water for bathing 0
