High Temperature Commercial Air To Water Heat Pump 10p Top Blowing Air Source

High Temperature Commercial Air To Water Heat Pump 10p Top Blowing Air Source

    • High Temperature Commercial Air To Water Heat Pump 10p Top Blowing Air Source
    • High Temperature Commercial Air To Water Heat Pump 10p Top Blowing Air Source
    • High Temperature Commercial Air To Water Heat Pump 10p Top Blowing Air Source
    • High Temperature Commercial Air To Water Heat Pump 10p Top Blowing Air Source
  • High Temperature Commercial Air To Water Heat Pump 10p Top Blowing Air Source

    Product Details:

    Place of Origin: Guangdong, China
    Brand Name: Meeting
    Certification: CE, RoHS, CCC,ISO,GMC,UKAS, CE,CCC,ISO,RoHS
    Model Number: MD100D-10

    Payment & Shipping Terms:

    Minimum Order Quantity: 5
    Packaging Details: Export standard plywooden case with water-proof film inside.
    Delivery Time: 15
    Payment Terms: L/C, T/T
    Supply Ability: 2000piece/pieces per Month
    Contact Now
    Detailed Product Description
    Warranty: 1 Year Power Source: Electric
    Installation: Freestanding Housing Material: Coated Metal , Stainless Steel Can Choose
    Application Field: Domestic,commercial,industrial Compressor: Copeland
    Controller: LCD Finger Touch Throttle: Sanhua Electric Expansion Valve
    General Using Places: Home,hotel,school,commercial Buildings
    High Light:

    air temp heat pump

    ,

    domestic air source heat pump

    Specification


    Working air temp -20℃—45℃
    Water flow 12000L/H
    Pipe size DN32
    Super quiet Noise ≤70Db
    Evaporator Finned heat exchanger
    Condenser Double pipe heat exchanger
    Rated input power 9.2KW
    Rated heating capacity 26KW
    Hot water supply 560L/H
    Rated voitage 380V/50HZ
    Rated current 18A
    Maximum outlet water temperature 80℃
    Compressor Copeland

    Remarks:The test conditions of above parameter :dry bulb temperature :20℃,wet bulb temperature :17℃, Inlet water temperature 15 degree , Outlet water temperature 80degree



    High Temperature Commercial Air To Water Heat Pump 10p Top Blowing Air Source 0


    Meeting air source heat pump water heater features:


    1. Complying with ISO standard. High Quality Ensured with the European standard.

    2. Using reliable compressor( Copeland Scroll/Panasonic) with R417A/407C/R404A/R410A refrigerant.

    3. Equipped with high efficiency tube in shell heat exchanger, finned heat exchanger or plate heat exchanger. All heat exchangers with insulation to prevent heat loss.

    4. Evaporator using surface modification of wave hydrophilic aluminous foil .

    5. Intelligent controller with LCD display control panel. Intellectual control over water pump, water supplement, water discharge and defrosting system.

    6. Automatic defrosting function included (with reverse valve inside).

    7. Low noise fan motor.

    8. General and operational test carried out for every unit before package in the factory.



    Packing & Delivery




    High Temperature Commercial Air To Water Heat Pump 10p Top Blowing Air Source 1

    To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided, our package is ply-wooden case, needn't fumigation.





    Company Profie




    High Temperature Commercial Air To Water Heat Pump 10p Top Blowing Air Source 2

    Our company have 19 years experience on manufacture heat pump and other home appliance, we build our own industry park, we have outstanding R&D team, we gain a lot of honor and certificate in the past years, and we never stop development in future.





    FAQ




    Q1: Regarding our company

    Our company establish in 2001, we are a manufacturer which have more than 18 years experences on produce heat pump.

    We have own brand --Meeting.

    We built our own industry park, our company is located in JinGu High-Tech-End Area, Huadu District Guangzhou, China, near Baiyun International Airport, welcome to contact with us and visit our company!



    Q2: Regarding our products

    Our products are manufactured strictly according to international standard. We got a lot of certifications and testing report; please kindly tell me if you need the certification.



    Q3: Regarding the MOQ

    The MOQ is 1 set, and we suggest using Alibaba Trade Assurance to protect both benefit.



    Q4: Regarding the package

    Our package is plywood with dusty-proof film, do not need fumigation.



    Q5: Regarding delivery

    Usually deliver by sea, for our regular equipment, deliver time is about 15 days. For OEM orders, will be further negotiate with us.
