Home ProductsGround Source Heat Pump

Economical Safety Ground Source Heat Pump Constant hot water supply Environmental friendly

Economical Safety Ground Source Heat Pump Constant hot water supply Environmental friendly

    • Economical  Safety Ground Source Heat Pump Constant hot water supply Environmental friendly
  • Economical  Safety Ground Source Heat Pump Constant hot water supply Environmental friendly

    Product Details:

    Place of Origin: Guangzhou China
    Brand Name: Meeting
    Certification: CE ISO CCC UKAS,ROHS
    Model Number: MDS200D

    Payment & Shipping Terms:

    Minimum Order Quantity: 5 PCS
    Price: Negotiation
    Packaging Details: Plywooden case
    Delivery Time: 15 days
    Payment Terms: T/T, L/C WESTERN UNION
    Supply Ability: 800/MONTH
    Contact Now
    Detailed Product Description
    Materail: Galvanized Steel Sheet Contactor: Fuji Brand
    Copper Pipe Thick: 1 Mm Compressor: ZW Series ,With Crank Heating
    Working Temperature: -20--45 Degree Insulation: Foam Pack Pipe And Stick On The Machine Innner
    Defrosting: Automaticlly Temperature: 80 Degree
    High Light:

    groundwater heat pump


    underground heat pump

    20P ground source machine_MDS200D ground source heat pump_Copeland compressor


    Technology Specification



    Ground source heat pump feature

    1. Economical operation

    Generally cost less to operate than other types of conventional heating systems, save your electricity or gas bills.

    2. Safety

    Operate at a high efficiency with no flames, fumes, or flues; Water and electricity isolated

    3. Environmental friendly

    Transfer heat that’s already in the environment; Low CO2 emissions.

    4. Easy operation

    With intelligent control systems which convenient and simple operation

    5. Constant hot water supply

    Provide hot water no matter in cloudy day, snowy day or at night, unlike solar collectors which have to be facing the sun.

    6. Wide application

    7. Heat pump water heater can be applied to sanitary hot water, house heating .



    Ground source heat pump installation different situations

    The ground source heat pump can also be called a soil source. It is buried in underground soil with high-polyethylene U-shaped pipe filled with water and antifreeze. The two ends of the pipe are connected to the evaporator in the ground source heat pump. Water and antifreeze are The circulation in the pipelines will continuously transfer the heat in the soil to domestic water.


    Packaging & Shipment

    1> Meeting heat pump can sure delivery heat pump within 5~20 working days as we warehouse stock condition.

    2> Heat pump with strong plywood pallet , strong plywood box for loading, make sure no problem happen during rude transporattion .

    3> All spare parts of the heat pump water heater will together loading into package , one time finished shipment to buyer.

    4> Take video of the heat pump for buyer before package to 100% sure buyer get product same as order, no any different.

    5> Meeting heat pump offer 100% test online, 5% test in Lab by 24 hour for one lot order (if not new model)

    Packaging Details :Standard export packing -with plywoods case packages,OEM is available for Factory price heat pump water heaters

    Delivery Time :15 work days after arrival of down payment



    Business Organizations

    Supermarket, shopping malls, shops, department store, star-rated

    hotels, restaurants, school, office;

    Public Places

    subway, airports, stations, bookstores, exhibition halls, stadiums, museums, commercial buildings, hospital;

    Entertainments Movie theaters, clubs, bars, cafes, Internet bars, beauty shops


    After selling:
    1. We promise to offer free consulting call in 7~24 hours mode to solve the problems found in practice.
    2. Products guarantee is 18~24 months from ex-factory date. Within 18months,if any components of your products damaged because of quality, we supply new replacement for free.
    3. After the expiration of the quality assurance, we will continue to provide lifelong maintenance services, with just charging some cost price.



    1. Complying with ISO standard. Quality Ensured.

    2. Complete Inspection for each unit before out of factory, covering water system and electricity detection and testing, ensuring 100% right product before shipment.

    3. Strict quality control during production. We have liquid soap detection, halogen detection, electrical detection and water-soaking detection during production to avoid gas leakage and electrical problems .

    4. Full inspection on bigger parts such as compressors, condensers, evaporators, expansion valves, flow switches, controllers etc.. Selection inspection for small parts such as sensors, pressure switches etc..

    5. Well noise control by using mute cotton for casing plates and soft rubber feet for floating compressors, some of the models use compressor isolation shields.

    6. Well insulated with insulated cotton for every pipe and parts, include compressor, dryer filter and each pipes.

    7. We have passed TUV and SGS inspections. We have CE, RoHs, IEC, CCC, CB certificates for most of our products. Some of our products have en14511 test, en14825 test.



    Porduct Detalis:

    Rated heating capacity KW 74
    Hot water supply L/h 1590
    Average heating input power KW 17.6
    Rated heating input current A 36
    Max outlet water temp 80
    COP   4.6
    Power V/Hz 380V/50
    Noise Db(a) 58
    Dimension W*D*H mm 1260×850×860
    Packing size W*D*H mm 1350×910×1020
    Unit weight KG 630
    Refrigerant   R417A/R407C
    Working air temp range (-40℃)—45℃
    compressor Type   Copeland
    water source heat exchanger Type   Plate heat exchange
    Pipe size DN 63
    Hot water side heat exchange Type   Coil heat exchanger
    Water flow M3/H 20000L/h
    Water pressure down Kpa 55
    Pipe size DN 50
    Max house heating M2 600
